Setting up an Ethernet connection for the Fusion Pro, Fusion Edge, and Fusion Maker laser systems (models 16000 – 17000) ensures reliable communication between the laser and your computer. There are two primary connection methods: a direct connection, where the laser is linked directly to a computer, and a network connection, where the laser is integrated into a larger network. This guide provides step-by-step instructions to configure both types of connections, including selecting the appropriate network settings and configuring the TCP/IP port if necessary. By following these steps, users can establish a stable and efficient Ethernet connection for seamless laser operation.
There are two types of Ethernet connections.
- Direct connection: laser is connected directly to the computer.
- Network connection: laser is connected to the network.
Direct Connection
- Power ON the machine.
-
Connect the laser to the computer with an Ethernet cable.
-
Click the gear icon in the top right corner of the display panel.
-
Select Network.
-
Select Ethernet.
Note: If you don’t see that option, you may need to click the edit button at bottom center of the screen.
-
Select Use the following IP Address. In the IP Address field enter 192.168.3.10
Note: This is the standard IP address for direct connection.
-
Configure you TCP/IP Port settings.
- TCP/IP Port setup is only required for direct connections.
- If you haven’t set up the TCP/IP port on the computer you will need to follow the instructions below.
Network Connection
-
Connect the laser to the network with an Ethernet cable.
-
Click the gear icon in the top right corner of the display panel on the laser.
-
Select Network.
-
Select Ethernet.
Note: If you don’t see that option, you may need to click the edit button at bottom center of the screen.
-
Select Obtain IP Address Automatically.
-
Click the green arrow to complete set up.
